ELEKTRISCH INS-F LV
High Performance Electrical Insulation Fluid
NORC ELEKTRISCH INS-F LV is a high performance and high efficiency electrical insulation fluid that was developed to maximize performance and productivity. NORC ELEKTRISCH INS-F LV was specially engineered using the highest quality raw materials to...
- Catalogue source
- Description page 204; technical page 205
NORC ELEKTRISCH INS-F LV is a high performance and high efficiency electrical insulation fluid
that was developed to maximize performance and productivity.
NORC ELEKTRISCH INS-F LV was specially engineered using the highest quality raw materials to withstand
energy spikes in extremely hot and cold climates. It is produced using Sulphur free base stocks to prevent
corrosion. The special negative gassing effects and increased flash point reduce the risk of fire and explosion.
NORC ELEKTRISCH INS-F LV is a fully inhibited oil designed to meet the requirements needed by the latest power
transformers, providing outstanding performance and protection which minimize breakdowns and reduce maintenance
costs.
that was developed to maximize performance and productivity.
NORC ELEKTRISCH INS-F LV was specially engineered using the highest quality raw materials to withstand
energy spikes in extremely hot and cold climates. It is produced using Sulphur free base stocks to prevent
corrosion. The special negative gassing effects and increased flash point reduce the risk of fire and explosion.
NORC ELEKTRISCH INS-F LV is a fully inhibited oil designed to meet the requirements needed by the latest power
transformers, providing outstanding performance and protection which minimize breakdowns and reduce maintenance
costs.
- Extended oil life
- Excellent oxidation performance
- Excellent protection against corrosion
- Excellent low temperature viscometric properties
- Free from Sulphur
- Less breakdowns and maintenance expenses
- Maximize performance and productivity
- Proper heat transfer inside transformers
- Reduce the risk of fire and explosion
- Suitable for use in extreme hot and cold climates
- ASTM D3487
- IEC 60296
Technical Details
Catalogue DataTECHNICAL DETAILS
* Further Values
Available Upon
Request
205 Litres ℮
PROPERTY
UNIT
ELEKTRISCH
INS-F LV
Kg / L
Cst
ul/min
mg KOH / g
⁰C
⁰C
0.84
6.1
53
Not Present
< 0.01
145
- 51
Specific Gravity @ 15⁰C
Kinematic Viscosity @ 40⁰C
Gassing Tendency
Corrosive Sulphur
Total Acid Number (TAN)
Flash Point (COC)
Pour Point
ASTM D3487
IEC 60296
Technical data is indicative catalogue information. Confirm the latest official data sheet before use.
Standard Packaging
- 205 Litres
